Roland Bn20 Desktop Printer&Cutter for Sticker/Label/T-Shirt Transfer Printing
Original 20" Roland Full-New Versa Studio Bn-20 Desktop Printer & Cutter Overview:The BN-20 packs everything into one, powerful, profit-producing package. With award-winning eco-solvent inks including metallic and white options, a range of material compatibility and integrated contour cutti......
Send Inquiry
Product Description
Overview:
The BN-20 packs everything into one, powerful, profit-producing package. With award-winning eco-solvent inks including metallic and white options, a range of material compatibility and integrated contour cutting, the BN-20 is easily the most versatile print device in its class. The BN-20 is perfect for creating t-shirt graphics, poster prints, stickers and decals - all from the comfort of your desktop.
Specifications:
| Model | VersaStudio BN-20 | |
|---|---|---|
| Printing method / Cutting method | Piezoelectric inkjet / Grit roller feed | |
| Acceptable media | Width | 5.9 to 20.3 in. (150 to 515 mm) |
| Thickness | Printing: Maximum 39 mil (1.0 mm) with liner | |
| Cutting: Maximum 16 mil (.4 mm) with liner | ||
| Roll Weight | Maximum 13.2 lbs (6 kg) | |
| Roll Outer Diamater | Maximum 5.9 in (150 mm) | |
| Core Diamater | 2 in (50.8 mm)or 3 in (76.2 mm) cores | |
| Printing/cutting width1 | Maximum 18.9 in (480 mm) | |
| Ink cartridges | Type | |
| Ink Cartridges | Type & Capacity | Roland ECO-SOL MAX or FPG Aqueous, 220 ml only |
| Colors | 5 Color - CMYK+Mt (Cyan, Magenta, Yellow, Black and Metallic Silver) or CMYK+Wh (Cyan, Magenta, Yellow, Black, and White) | |
| 4 Color - CMMYK (Cyan, Magenta, Yellow, Black) | ||
| Printing resolution | Max 1440 dpi | |
| Cutting Blade | Type | Roland CAMM-1 series cutter blade |
| Blade Offset | Fixed at 0.250 mm | |
| Cutting speed | 0.4 (10 mm/s) to 5.9 in/s (150 mm/s) | |
| Blade force | 30 to 300gf | |
| Software resolution (when cutting) | 0.000984 in/step (0.025 mm/step) | |
| Distance accuracy (when printing)2,3 | Error of less than ± 0.3 % of distance traveled, or ± 0.3mm (0.012 in), whichever is greater. | |
| Distance accuracy (when cutting)2,4 | Error of less than ± 0.4 % of distance traveled, or ± 0.3mm (0.012 in), whichever is greater. | |
| Repetition accuracy (When cutting)2,5 | ±0.004 in (± 0.1mm) or less | |
| Alignment accuracy for printing and cutting2,6 | ±0.020 in (± 0.5mm) or less | |
| Alignment accuracy for printing and cutting when reloading media2,7 | Error of less than ± 0.5% of distance traveled, or ± 0.012 in (3mm), whichever is greater | |
| Print Heater Temperature8 | Fixed at 95o F (35oC) | |
| Connectivity | USB 2.0 | |
| Power-saving function | Automatic sleep feature / AC 100 to 240V ± 10%, 1.5 A, 50/60 Hz | |
| Power Consumption | During Operation | Approx. 90 W |
| Sleep Mode | Approx. 5.5 W | |
| Acoustic Noise Level | During Operation | 62 dB (A) or less |
| During Standby | 42 dB (A) or less | |
| Dimensions/Weight | 39.2" W x 23" D x 11.5" H (995 W x 585 D x 291 H mm), 79.4 lbs (35 kg) | |
| Operating Conditions | Power on | Temperature: 68o - 90o F (20 to 32o C), humidity: 35 - 80% RH (non condensing) |
| Power off | Temperature: 41o - 104o F (5 to 40o C), humidity: 20 - 80% RH (non condensing) | |
| Included Items | Power cord, USB cable, blade, blade holder, Rolandsoftware Package9, Software RIP (VersaWorks), User's Manual, etc | |
Features
- Integrated printing and cutting in a 20-inch desktop inkjet
- Tshirt printing machine and tshirt printing press
- Sign making machine
- Eco-Sol MAX ink in CMYK, CMYK+Mt (Metallic Silver) or CMYK+W (White)
- Roland automated Ink Circulation System for economical operation
- USB interface
- Compatible with Windows® 7, Vista and XP operating systems
- Supports popular Windows design software including CorelDRAW® and Adobe® Illustrator®
- Energy Star® Certified
- Bundled software
- Roland VersaWorks® RIP software
- R-Works design software
- Windows driver
- Roland OnSupport online production monitor
Notifications:
| *1 The length of printing or cutting is subject to the limitations of the program. | ||
| *2 Using Roland specified media, loaded correctly, temperature: 25°C (77°F), humidity: 50 %RH, all pinch rollers are used, 25 mm or more for both right and left margins and 35 mm or more front margin, excluding expansion or contraction of the emdia, and all correction and adjustment functions of this machine have been made properly. | ||
| *3 Using Roland specified media, print travel of 1m. | ||
| *4 Using Roland specified media, cut travel of 1m. | ||
| *5 Range for assured repetition accuracy: Length 1,000 mm. | ||
| *6 Provided that media length is under 1,000 mm. Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media. | ||
| *7 Using Roland specified media, data size: 1,000 mm in the media-feed direction, 480 mm in the carriage-movement direction. No lamination. Automatic detection of crop marks at 4 points when media is reloaded. Excludes the effects of skewed movement and of expansion and contraction of the media. | ||
| *8 Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment. The preset temperature may fail to be reached 35°C (95°F) depending on the ambient temperature and media width. | ||
| *9 Roland Software Package includes: Windows driver, OnSupport software, utility software and R-Works design software |
Applications:
Vibrant Heat Transfers
Custom Labels
Eye-Catching Decals
Contour Cut Window Graphics
