Semiautomatic Screen Printer T1100

Model T1100
It is semiautomatic screen printer which has PLC program controlling, high accuracy, low
Malfunction; The lift of support shelf and scraper is driven by air, there are speed valve in exit
And entrance which can adjust speed; The speed of scraper is controlled by motor, speed timing
Of motor can control motor speed; Scraper is made of steel stainless
Main technology parameters
Max PCB 230× 180mm (Standard), 220*240( optional)
Working table area 300× 300 mm
Template size 300× 400 mm

Air pressure 0.4-0.7Mpa
Input voltage AC220V
Max power 50W
Dimension 740× 554× 400mm
T1100 is a high accuracy semiautomatic printing machine. The operator only needs to press the
Double switch button at one time. Then the printing machine will automatically finish the single
Pass of the printing process. After the printing is done, take out the PCB plate and put it into the
Turnover box or directly into the mount machine. In the end put another PCB in the printing
Machine to go on with the next printing cycle.
Features for this model: Simple operation, high accuracy, easy to be adjusted, widely used and
So on.
1. PLC control system.
2. Panasonic gear motor.
3. The imported linear guide track keeps smooth and exact printing

Lift air cylinder of back scraper
Lift air cylinder of front
Scraper
X axes
Adjust height of
Template
Height fixed handle

Configuration
1. Bench top semiautomatic screen printer T1100 1 set
2. Accessory
A. Position thimble 6
B. Support thimble 8
3. Accessory:
A. Testing report 1
B. Using manual
Adjust angle
Speed timing of motor
